Star W-109
STAR W-109 03
Type Assault rifle
Place of origin Euskadi
Service history
In service 2010-
Production history
Designer STAR
Designed 2009
Manufacturer STAR
Produced 2010-
Variants A1 & A2
Specifications
Weight A1
3.5 kg
A2
3.3 kg
Length A1
910 mm (butt extended) - 670 mm (butt folded)
A2
855 mm (butt extended) - 587 mm (butt folded)
Barrel length A1
360 mm
A2
277 mm
Width 112 mm (butt extended) - 77 mm (butt folded)
Height 260 mm

Cartridge 5.56x45mm NATO, 7.62x39mm
Action Gas-operated, rotating bolt
Rate of fire 760 rpm
Effective range A1
500 m
A2
400 m
Feed system 20, 30 or 100 Round box magazine
Sights Iron sights with accessory rail

The Star W-109 assault rifle was first introduced to the public in 2009, as a possible future replacement for the dated Star W-91 assault rifle still in use by Euskadiko Indar Armatuak. In 2010, the W-109 was selected as a next standard military rifle for Euskadiko Indar Armatuak, with production contract issued to STAR. It is quite possible that W-109 rifles also will be offered for export, either in military (select-fire) or in civilian (semi-automatic only) versions.

Features

STAR W-109 02

W-109 A2 assault rifle with short barrel, butt folded, iron sights raised

The Star W-109 is assault and modular rifle manufactured in 5.56x45mm NATO and 7.62x39mm calibres which has been designed as personal weapon for any combat branch. From the functioning point of view, this is a gas operated automatic weapon with locked breech having rotary breech block.

Its modular concept and the unified system of interchangeable barrels attachment, using exchangeable breech block and gas tube, allows easy and quick conversion to a different calibre. The design of interchangeable magazine well enables utilisation of the standard M-16 magazines implemented by NATO, including high-capacity magazines for company automatic weapons. All the barrels have been adapted to accommodate fitting of the flash suppressor and silencer. The unified, easily detachable trigger mechanism has been provided with the four-position firing mode selector (0 – 1 – 2 – continuous bursts). The entire receiver upper section and the bottom have been provided with mount rails compliant with the MIL-STD 1913. The folding shoulder stock features an ergonomic shape and it is vertically adjustable. The folding optical sights have been designed for aimed shooting up to the range of 500 m. The easily adjustable bolt cocking lever facilitates handling of the weapon by left-handed shooters.

STAR W-109 04

Soldiers of Eusko Gudarostea equiped with W-109

The standard accessories for the W-109 system include, besides other, the modular (assault/combat bayonet) featuring original design by STAR together with the three-point suspension strap . This weapon can be also equipped with the underslung grenade launcher designated as the Star 805 G1 in 40x46 cal., which was developed specifically for this weapon with option for the stand-alone use.

The characteristics of W-109 weapon family are the long service life and reliability under various combat conditions. The modular system of this weapon provides for numerous versions and modifications of the basic model of the assault rifle (A1), especially the carbine with shortened barrel version (A2), the light sniper rifle version or even the conversion into the light machine-gun.

The Star W-109 rifle is manufactured from selection of quality steels, high-strength aluminium alloys and the latest construction plastics together with application of the most modern technologies for surface protection. Thanks to the sophisticated design and cutting-edge technology the W-109 carbine excels in high service life and reliability in all types of combat deployment.
